Headlights wiring diagrams needed

2015 HONDA CIVIC
25,000 MILES
Avatar
DAN ROZETT
  • MEMBER
  • 3 POSTS
I scratched a new low beam halogen bulb on my car listed above SE, while installing it. Should I replace it? I think it might have messed up because the headlight stopped working I need to wiring diagrams so I can see how the system works?
Aug 29, 2020 at 11:04 AM
Advertisement
Avatar
DANNY L
  • CERTIFIED EXPERT
  • 5,648 POSTS
Hello, I'm Danny.

Here is a guide to help check the wiring connections with the headlight wiring diagrams for both hybrid and non hybrid models below.

https://www.2carpros.com/articles/how-to-check-wiring

Check out the diagrams (Below). Please let us know what happens.
Images (Click to enlarge)
Attached Media
Attached Media
Attached Media
Attached Media
Attached Media
Attached Media
Attached Media
Attached Media
Aug 29, 2020 at 12:01 PM
Avatar
DAN ROZETT
  • MEMBER
  • 3 POSTS
Hi Danny. Here is a picture of one headlight not working Thanks for the reply. Tried uploading again. Hope it works.
Image (Click to enlarge)
Attached Media
Aug 29, 2020 at 12:02 PM
Advertisement
Avatar
DANNY L
  • CERTIFIED EXPERT
  • 5,648 POSTS
Hello again.

Yes, I got it. Remember when installing bulbs to wear latex or nitrile gloves due to the bulbs being touched by your hand will blow the bulb from the oil in our skin. Hope this helps and thanks again for using 2CarPros.

Danny-
Aug 29, 2020 at 1:14 PM
Avatar
DAN ROZETT
  • MEMBER
  • 3 POSTS
Yup, dropped it when installing. Survived the drop but got scratched. Installing on driver’s side of this car is annoying... access is anything but ideal.
Thanks for your advice.
Dan
Aug 29, 2020 at 1:42 PM
Avatar
DANNY L
  • CERTIFIED EXPERT
  • 5,648 POSTS
Hello again.

Hope all goes well with the install.Thanks again for using 2CarPros and hope you will use our site again in the future.

Danny-
Aug 29, 2020 at 1:47 PM
